S330/2

HORIZONTAL MITERING SAW

• 3 H.P.
• 12" x 18" Capacity
• 1″ Blade
• Swivel Head
• 60° Miter Cutting
• Hydraulic Vise
• VFD

• FEATURES

  • Hydraulic Down Feed

    • Infinitely variable feed rate is hydraulically controlled for fast, accurate cutting. Settings are made at the operator’s control station.
  • Hydraulic Auto Frame Return

    • The saw frame will automatically raise hydraulically at the end of a saw cut. The saw frame can also be lifted hydraulically with the push button switch.
  • Chip Brush

    • Powered from the drive wheel of the saw, the brush changes speed with the blade to assure that chips are being removed from each gullet, improving cutting performance and blade life.
  • Swivel Miter

    • The saw frame swivels a full 60 degrees to the rear and 45 degrees to the front for optimum miter cutting capability. Stops are provided at -60 and +45 degrees.
